Inova 76mm Middle Gasket
For maximum insulation...
- Inova 76mm System aims to provide maximum heat and sound insulation having 7 chambers, 3 gaskets (with middle gasket) and special glass that has 50mm width.
- In addition to high insulation values, the system provides significant benefits in terms of environmental and economical sustainability by being a longlasting product.
- Containing an additional central gasket besides of frame and sash gaskets, the profile system provides maximum heat and sound insulation.
- The system provides the advantage of fast production thanks to the profiles manufactured as gaskets included.
- TPE gasket included in the profile system provides high insulation thanks to weldability around the corner.
- By applying heat-insulated aluminium threshold profile, it enables threshold application at lower height.
Product Dimensions
- Frame Width: 76 mm
- Frame Height inside-outside: 42 - 46 / 68 - 72 mm
- Mullion Width inside-outside: 42 / 94 mm
- Sash Width Standard - Self Drainage: 76 - 86 mm
- Window Sash Height: 57 - 55 / 83 mm
- Balcony Door Sash Height: 75 - 73 / 101 mm
- Door Sash Height: 105 - 103 / 131 mm
- Glass thickness: 24 / 50 mm
- Number of Chamber for Frame Profiles: 5, 6, 7
- Number of Chamber for Sash Profiles: 4, 5, 6, 7
- Number of Chamber for Mullion Profiles: 4, 5, 6
Color Options
Laminated Colour/Design Options
Dark Oak
Dark Oak
-470.jpg)
Golden Oak
Golden Oak
Siena
Siena
Wallnut
Wallnut
Anthracite Grey (7016)
Anthracite Grey (7016)
Crem White (1379)
Crem White (1379)
Quartz Grey (7039)
Quartz Grey (7039)
Anteak
Anteak
-483.jpg)
Trompet
Trompet
Aluminium Brush
Aluminium Brush
Cottony Winchester
Cottony Winchester
Winchester (49252)
Winchester (49252)
-475.jpg)
Gale Grey (49122)
Gale Grey (49122)
Black Ulti Matt
Black Ulti Matt
