Diamond 60
- To ensure maximum sound and heat insulation in series of 70-60 mm, it is possible to be used with quality glass between the range of 4, 20, 24, 30mm.
- It stands out particularly in mass housing projects with its high quality and economic solutions.
- It provides alternative solutions for different needs arise in housing alterations.
- It is ideal product also for prefabricated constructions and container houses.
- It offers different appearance possibility with its flat sash and fluted sash applications.
- It provides wall – joinery connection integrity with aesthetic appearance on the inner surface with the groined case profile.
- It operates in concordance with screen, louver and shutter systems.
- By means of its design which makes the water discharge easier, its water tightness is high.
Product Dimensions
- Profile Width: 60 mm
- Number of Chambers: 3, 4 chambers
- Profile Class: B CLASS
- Seal System: Interior / exterior seal
- Seal Type / Colour: EPDM, TPV seal type / Colour: Black or grey
- Glass Thickness: 4, 20, 24, 31mm
Colour Options
Laminated Colour/Design Options
Dark Oak
Dark Oak
-470.jpg)
Golden Oak
Golden Oak
Siena
Siena
Wallnut
Wallnut
Anthracite Grey (7016)
Anthracite Grey (7016)
Crem White (1379)
Crem White (1379)
Quartz Grey (7039)
Quartz Grey (7039)
Anteak
Anteak
-483.jpg)
Trompet
Trompet
Aluminium Brush
Aluminium Brush
Cottony Winchester
Cottony Winchester
Winchester (49252)
Winchester (49252)
-475.jpg)
Gale Grey (49122)
Gale Grey (49122)
Black Ulti Matt
Black Ulti Matt
Product Performance
- Profile Heat Transfer Coefficient: performance is not designated
- Glass Heat Transfer Coefficient: 31 (-1,-6) (without interlayer)
- Window Heat Transfer Coefficient: performance is not designated
- Air Permeability: 4
- Water Isolation 9A/E1050/E750
- Wind Load Resistance: C1/A3, C2/A4
- Acoustics Performance: 31[-1,-6] dB
Application Options
Please click on in order to see the PDF document which contains the application options related with the products.
